Adorbond +

Description

>>> GebrAnw-Dental-Base-Alloy-Adorbond+.pdf <<<

Type:	Gold-reduced metal-ceramic alloy on the gold basis, type 4 (extra hard) acc. DIN EN ISO 22674
Colour:	white



Applicable scope:	Inlays, Onlays	●
	Crowns	●
	Small bridges	●
	Large-span bridges	●
	Milling, cone and attachment works	●
	Modeling casting	●



Composition:	Au	51,60
(mass fraction in %)	Pd	38,40
	Ir	0,05
	Ru	0,05
	In	8,40
	Ga	1,50



Technical specifications:	Density in g/cm³	13,8
	Vickers hardness HV 5/30	(s)220 (n)220 (a-n)230
	Yield strength Rp0,2 in MPa	(s)470 (n)530 (a-n)560
	Elongation at break in %	(s)31 (n)30 (a-n)29
	Average linear CTE 25 – 500 °C in 10-6 K-1	13,5
	Average linear CTE 25 – 600 °C in 10-6 K-1	13,8
	Elastic modulus in GPa	110
	Melting interval in °C	1200 - 1310



Processing:	Preheating temp. of the casting moulds in °C	900
	Casting temperature in °C	1460
	Crucibles	Ceramic
	Curing	500°C/15min



Suitable solders:	Joints before ceramic firing	AL 1060 W
	Joints after ceramic firing	AL 750



1) Brief description:

s – self-curing, n – after ceramic firing, a-s – curing from s condition

a-n – curing from n condition



2) All information about cured condition is given according to the alloy:

– Oxide firing 10min/ 960°C + 4x4min/ 960°C for yellow conventional bonding alloys

– Oxide firing 10min/ 980°C + 4x4min/ 980°C for white conventional bonding alloys

– Oxide firing 10min/ 800°C + 4x4min/ 800°C for LFC-systems

Corresponding data are true under these conditions only.



3) The ceramic firing should be carried out according to the manufacturer's instructions.
